Foob qhov Deal: Yuav Ua Li Cas Ntsuas Pneumatic Fitting Performance & Vim Li Cas Nws Tseem Ceeb
Views: 1 Author: Site Editor Publish Time: 2026-01-20 Keeb Kwm: Qhov chaw
Nug
Leaks yog cov uas ntsiag to killers ntawm pneumatic efficiency. Ib qho kev sib haum xeeb ib leeg tuaj yeem ua rau poob siab, spiking zog tus nqi, tsis zoo actuator txav, thiab kim downtime. Rau cov neeg tsim qauv thiab cov kws kho tsheb, kev nkag siab yuav ua li cas txhawm rau txheeb xyuas lub foob tsis yog tsuas yog kev tswj kom zoo - nws yog qhov tseem ceeb rau kev ua haujlwm kev ntseeg siab thiab muaj txiaj ntsig.
Ntawm
REAYON PNEUMATIC , lub
tuam txhab ua lag luam ntawm cov khoom siv hluav taws xob ua kom muaj zog, peb xav txog kev sib foob nruj rau qhov tsis sib tham ntawm peb cov txheej txheem tsim khoom. Ntawm no yog kev ua haujlwm ntawm cov txheej txheem tseem ceeb thiab cov kev xav hauv qab pneumatic haum rau kev kuaj pom.
Lub Ntsiab Tseem Ceeb: Peb Ua Dab Tsi Rau?
Ua ntej siv ib txoj kev, txhais lub hom phiaj. Kev xeem validates peb tus ncej:
Leak Rate Integrity: Kev txheeb xyuas tias cov dej xau yog qis dua qhov kev tso cai (piv txwv li, <1x10⁻⁶ mbar·l/s).
Kev Ntsuas Kev Ntsuas Siab: Lub foob yuav tsum tuav ntawm lub tshuab nqus tsev kom tsawg kawg yog 1.5x qhov ntsuas kev ua haujlwm siab.
Durability Nyob rau hauv Kev Nyuaj Siab: Kev ua tau zoo yuav tsum nyob twj ywm tom qab rov txuas / txiav cov voj voog, qhov kub thiab txias, thiab kev co.
Cov txheej txheem no raug ntsuas raws li cov qauv thoob ntiaj teb xws li ISO, SAE, thiab peb tus kheej, nruj dua, cov lus qhia sab hauv.
REAYON Leak-Test Arsenal: Los ntawm Basic mus rau Kub-Standard
Kev txheeb xyuas cov txheej txheem muaj xws li los ntawm cov khw muag khoom hauv pem teb yooj yim mus rau kev soj ntsuam qib qib. Ib qho kev pabcuam zoo, zoo li peb ntawm
REAYON PNEUMATIC , feem ntau ua haujlwm ua ke.
1. Siab Decay / Tuav Test (Kev Lag Luam Ua Haujlwm)
Qhov no yog qhov feem ntau, ncaj qha txoj kev.
Txheej Txheem: Ib qho kev xeem Circuit Court uas muaj qhov haum yog pressurized, cais, thiab saib xyuas. Lub siab poob (ΔP) dhau lub sijhawm teem tseg yog ntsuas.
REAYON Insight: Thaum tus nqi zoo, nws qhov tseeb yog qhov hloov pauv kub. Peb cov kab ntau lawm siv thermally stabilized ib puag ncig kom ntseeg tau cov txiaj ntsig.
2. Npuas Immersion / Soap Solution Test (Lub Visual Locator)
Ib qho yooj yim brilliantly, qualitative txoj kev rau pinpointing leaks.
Txheej Txheem: Lub rooj sib txoos ua ke yog muab tso rau hauv dej los yog txhuam nrog xab npum. Ib tug kwj tsis tu ncua ntawm npuas qhia qhov xau qhov chaw.
Pro Ntsis: Ib txwm qhuav cov khoom kom huv si tom qab immersion los tiv thaiv corrosion-ib kauj ruam peb yeej tsis hla.
3. Sib Nqus Sib Nqus / Mass Flow Test (Lub High-Precision Sentinel)
Qhov no yog txoj kev xaiv rau cov khoom ntim siab, kev ntseeg siab ntau lawm.
Txheej Txheem: Nws piv cov siab los yog ntws hauv cov ntaub ntawv ntim rau qhov ntsuas ntim uas muaj qhov haum. Txhua feeb sib txawv yog ntsuas ntsuas.
Vim Li Cas Peb Siv Nws: Nws yog qhov tseeb, nrawm, thiab tsis tshua muaj suab nrov rau ib puag ncig, ua rau nws zoo meej rau
kev tsim khoom QC chaw nres tsheb.
4. Helium Mass Spectrometry Testing (Qhov Kev Ntsuas Tsis Txaus Siab)
Rau lub hom phiaj tseem ceeb daim ntawv thov qhov twg xoom leakage yog qhov tseem ceeb, qhov no yog qhov kawg xeem.
Txheej txheem: Lub haum yog them nrog helium tracer gas. Lub sensor loj spectrometer (xws li kev sojntsuam sniffer lossis hauv lub tshuab nqus tsev) kuaj pom cov helium me me tsis kawg.
REAYON Standard: Peb siv qhov no rau kev siv cov khoom tsim tshiab, cov ntaub ntawv pov thawj, thiab rau aerospace / semiconductor-qib cov khoom kab, kom ntseeg tau cov nqi xau tsawg li 10⁻⊃1;⊃2; mbar·l/s.
Decoding Failure: Dab tsi yog qhov Leak sim qhia koj
Kev xau yog ib qho tsos mob. Pinpointing nws qhov chaw qhia lub hauv paus ua rau:
Leak Qhov chaw
Tej yam ua txhaum
Xov Interface
Lub zog torque tsis raug, cov xov puas, lossis daim ntawv thov sealant tsis raug.
Tube Ferrule / Crimp Zone
Tube tsis tau muab tso tag, ua ntej swaging tsis ua, los yog tawm-ntawm-spec tubing.
O-Ring / Foob ntsej muag
O-ring loj / cov khoom tsis raug, foob kev puas tsuaj thaum lub sij hawm sib dhos, los yog qhov chaw tsis zoo ntawm qhov zawj.
Raws li cov chaw tsim khoom, peb tsim los tshem tawm cov kev ua tsis tiav no. Qhov no txhais tau hais tias precision-machined threads, optimized ferrule geometries, thiab qhia meej tshaj, high-durability foob cov ntaub ntawv.
5 Cov Lus Cog Tseg ntawm Kev Ntsuas Leak Zoo
Calibrate & Tsim nyog koj qhov kev xeem Circuit Court ua ntej. Lub xeem rig nws tus kheej yuav tsum tau leak-tight.
Kev huv huv yog qhov tseem ceeb. Cov khib nyiab ntawm qhov chaw sealing yog thawj qhov ua rau tsis ua haujlwm.
Ua raws li cov lus qhia kev txhim kho kev ntseeg. Qhov tob tob thiab torque yog qhov tseem ceeb. Peb muab cov lus qhia meej, meej nrog txhua yam khoom.
Tswj ib puag ncig. Tus account rau qhov kub thiab txias, tshwj xeeb tshaj yog nyob rau hauv cov kev ntsuas siab lwj.
Document Txhua yam. Cov ntaub ntawv taug qab-siab, lub sijhawm, qhov tshwm sim, tus neeg teb xov tooj-yog cov pob txha ntawm cov txheej txheem zoo.
Kab hauv qab:
Kev xaiv txoj kev xeem yog nyob ntawm koj qhov kev xav tau, kev xa mus, thiab kev siv nyiaj txiag. Los ntawm lub rooj cob qhia hauv pem teb mus rau qhov chaw sim siab, cov ntsiab lus tseem nyob: kev ntseeg siab, tab sis txheeb xyuas.
Ntawm REAYON PNEUMATIC, peb tsis yog tsim fittings xwb; peb engineer kaw, txhim khu kev qha kev sib txuas. Peb qhov kev cog lus rau kev sim ua kom tiav yog koj qhov kev lees paub ntawm kev ua haujlwm siab tshaj plaws thiab kev ua haujlwm ntev.
Tawm tsam tsis tu ncua los yog tsim lub tshuab tshiab? Wb tham txog yuav ua li cas peb precision-engineered fittings thiab daim ntawv thov kev txawj ntse tuaj yeem kaw qhov kev pom zoo ntawm koj qhov project tom ntej.
